ITEM NO : 2368026

Sleeve Coupling Flange Fixed Bore 2-3/8

TB WOOD'S

PART NO : 10S238

Sleeve Coupling Flange Size - Sleeve Couplings 10 Flange Type - Sleeve Couplings S Bore Type - Couplings Fixed Bore Bore Dia 2-3/8 In. Outside Dia 7.500 In. Keyway Size Type 5/8 in x 5/16 In. Length through Bore (In.) 2.72 Max RPM 3600 Width (In.) 2.72 Height (In.) 7.500 Hub Dia (In.) 7.500 Material of Construction Cast Iron Setscrew Location One over the Key and One at 90 Degrees Max Angular Misalignment 1 Degrees For EPDM Neoprene Sleeves 0.25 Degrees For Hytrel Sleeves

STOCK : available
UOM : EA lead time : 30 days weight : 4.85 kg
